Lenovo Tab M10 X605F/L

Media and communication State: Active

Description

The Lenovo Tablet TB-X605 was designed for multimedia purpose and is equipped with a good display and audio-module. There is also a dockingstation available, which can be used as bluetooth speaker and for charging the device.

Features & Usability

Automated Usability (beta)

Boots and runs well, essential features work correctly. It can be used as a mobile device running Ubuntu Touch OS. Recommended for advanced users.

Actors:
Manual brightness
Notification LED
Vibration

Camera:
Video
Switching between cameras

Cellular:
Carrier info, signal strength
Data connection
MMS in, out
PIN unlock
SMS in, out

Endurance:
24+ hours battery lifetime
7+ days stability

GPU:
Boot into UI
Hardware video playback

Misc:
Anbox patches (deprecated)
AppArmor patches
Battery percentage
Offline charging
Online charging
Recovery image
Reset to factory defaults
SD card detection and access
RTC time
Shutdown / Reboot
Wireless External monitor
Waydroid

Network:
Bluetooth
Flight mode
Hotspot
WiFi

Sensors:
Automatic brightness
GPS
Proximity
Rotation
Touchscreen

Sound:
Earphones
Loudspeaker
Microphone
Volume control

USB:
MTP access
ADB access

Working

Confirmed, depending on the maintenance

Not Working

If there is a link here, follow it to learn more''

Partial

Working to some extent but with issues

Global Issue

Issue is not specific to this device

Release channels

This device gets updates through these channels, learn more about OTA updates

Ubuntu Release	Channel	Version	Release Date	Description
Xenial	devel	2022-08-30/2	30-08-2022	Daily built development releases
Xenial	rc	2022-W30/2	28-07-2022	Testing before the next stable release
Xenial	stable	OTA-23	17-06-2022	Stability over newer features (recommended)

Lenovo Tab M10 X605F/L

Specifications

CPU	Octa-core 1.8 GHz Cortex-A53
Chipset	Qualcomm SDM450 Snapdragon 450 (14 nm)
GPU	Adreno 506
Storage	32 GB
Memory	3 GB
Android Version	9.0 (Pie)
Battery	4850 mAh
Display	256.54 mm (10.1 in) : 1920x1080 (224 PPI) - LCD IPS Touchscreen
Rear Camera	5 MP, No flash
Front Camera	2 MP, No flash
Architecture	arm64
Dimensions	242 mm (9.53 in) (w), 168 mm (6.61 in) (h), 8.1 mm (0.32 in) (d)
Weight	480 g
Release date	2018

Compatible Lenovo X605F/L versions

This port works well for the 3GB/32GB versions of this tablet.

There also exists a 2GB/16GB version, where it is not possible to flash a custom recovery image. That means, that you still can install Ubuntu Touch boot and system images manually by fastboot. But you will not be able to use the installer or get OTA updates.

Port Resources

Repository

Maintainers

Luksus

How to install Ubuntu Touch OS

You can install Ubuntu Touch on this device using the UBports Installer on your computer.
Unless device specific instructions are provided by the porter, please follow these general steps:

Unlock the bootloader, please search the internet for instructions
Install the required Android/stock rom version ¹
Select the appropriate installer package for your computer
Plug in your device and follow the on-screen instructions
The installer will take it from there

¹ Devices generally require a specific version of Android/stock rom to be installed. This depends on the halium version the port is build on. For example, if the port is based on halium 9, make sure you have Android version 9 installed before running the installer.

Linux

snap (try me first)

Debian

deb

AppImage

x86

Windows & Mac

Windows

exe x86

Mac

dmg x64

Failed to install?

The world hasn't come to its end yet. Try our troubleshooting channel on telegram group or try older versions of the installer if the problem keeps occurring. Lastly, you can guide throught the problem with our support team. Good luck!
